Basen av ONEPOLE LITE. Høyde 1200 mm. Tvillingversjon. Slank, men eksepsjonelt sterk og holdbar, designet med kostnadseffektive materialer for en rimelig, høykvalitets løsning. Ideell for private områder og hjem, og tilbyr en strømlinjeformet variant uten å kompromittere ytelsen. ONEPOLE LITE er produsert med sjøvannsbestandig aluminium og belagt med Jotun pulverlakk for optimal beskyttelse, selv langs kystlinjen. Tilgjengelig i ønsket RAL-farge for å passe til omgivelsene dine. Leveres med senteravstand på bolter C/C 140mm for feste til standardfundamenter eller ONEPOLE PRO Base Mount fundament. Fotplaten er designet for allsidige monteringsalternativer, noe som gjør at den enkelt kan installeres både på tak og gulv.
The base of the ONEPOLE. Height 1000 mm. Innumerable combinations and customization makes the ONEPOLE fit for any project. Can be rotated 180 degrees to be mounted to the ceiling in garages with limited space. ONEPOLE is produced with seawater-resistant aluminum and coated with Jotun powdercoat for optimal protection, even along the shoreline. ONEPOLE is available in desired RAL color to suit your surroundings. Delivered with center distance on bolts C/C 160 mm for attachment to standard foundations. The footplate is designed for versatile mounting options, allowing it to be easily installed on both ceilings and floors. ONEPOLE PRO 1000 is commonly used with ONEBLOC or other use cases where the ONEPOLE is mounted off the ground.
The base of the ONEPOLE. Height 1500 mm. Innumerable combinations and customization make the ONEPOLE a fit for any project. Can be rotated 180 degrees to be mounted to the ceiling in parking basements with limited space. ONEPOLE is produced with seawater-resistant aluminum and coated with Jotun powdercoat for optimal protection, even along the shoreline. ONEPOLE is available in desired RAL color to suit your surroundings. Delivered with centerdistance on bolts C/C 160 or 140 mm for attachment to standard foundations or ONEPOLE PRO Base Mount foundation. The footplate is designed for versatile mounting options, allowing it to be easily installed on both ceilings and floors.
The base of the ONEPOLE. Height 1500 mm. Innumerable combinations and customization make the ONEPOLE a fit for any project. Can be rotated 180 degrees to be mounted to the ceiling in parking basements with limited space. ONEPOLE is produced with seawater-resistant aluminum and coated with Jotun powdercoat for optimal protection, even along the shoreline. ONEPOLE is available in desired RAL color to suit your surroundings. Delivered with centerdistance on bolts C/C 160 or 140 mm for attachment to standard foundations or ONEPOLE PRO Base Mount foundation. The footplate is designed for versatile mounting options, allowing it to be easily installed on both ceilings and floors. Designed and supplied with ONEPOLE PRO DIN kit, which includes 4 tracks, screws, and 5 rubber grommets, ensuring a secure and hassle-free circuit breaker/connection kit installation. Impact resistance tested (IK 10 level of protection) Resistance to corrosion tested (salt spray) TUV Rheinland certified (Certificate No: AK 50596379)
The ONEPOLE PRO with Ø60 conversion has a height of 1500mm. Specifically engineered to mount directly onto Ø60mm pipes, this model also offers a convenient connection hatch and the capability for parallel connections. Its robust build and adaptability make it perfect for projects needing a steady and dependable pole solution with flexible connection options. Typical application is when replacing motorheaters with EV-Chargers.
The base of the ONEPOLE. Height 600 mm. Innumerable combinations and customization makes the ONEPOLE fit for any project. Can be rotated 180 degrees to be mounted to the ceiling in garages with limited space. ONEPOLE is produced with seawater-resistant aluminum and coated with Jotun powdercoat for optimal protection, even along the shoreline. ONEPOLE is available in desired RAL color to suit your surroundings. Delivered with center distance on bolts C/C 160 or 140 mm for attachment to standard foundations or ONEPOLE PRO Base Mount foundation. The footplate is designed for versatile mounting options, allowing it to be easily installed on both ceilings and floors. ONEPOLE PRO 600 is commonly used on the concrete walls/fences or other use cases where the ONEPOLE is mounted off the ground.
The ONEPOLE base features a custom-designed L-shape with dimensions of 500x1200 mm, offering endless combinations and customization options to suit any project. It can be rotated for ceiling mounting in space-constrained areas, such as parking garages. Crafted from seawater-resistant aluminum and coated with Jotun powdercoat, ONEPOLE provides optimal durability, even in coastal environments. Available in any RAL color to seamlessly blend with your surroundings, it comes with a bolt center distance of C/C 160 mm for compatibility with standard foundations. The versatile footplate design allows for easy installation on both ceilings and floors, with the option for customized measurements to meet specific project requirements.
The ONEPOLE Sixty is a standout mast top addition to the ONEPOLE PRO series, measuring at 625 mm in height. Its distinguishing feature is the ability to rotate 180 degrees, perfect for ceiling-mounting in spaces with limitations. Constructed from seawater-resistant aluminum and shielded with a durable Jotun powder coating, it's built for endurance, especially near the coastline. With its Ø60 pipe fitment, the ONEPOLE Sixty provides versatile mounting options, making it a go-to choice for setups requiring Ø60mm pipe integrations.
A single bracket specifically designed for the ABB Terra, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the ABL Wallbox eMH1, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the ABL Wallbox eMH2, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the ABL Wallbox eMH3, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Alfen Eve Double Pro-Line, complete with 316L stainless steel screws for customized EV charger installation. Optional cable holder/protector available.
A single bracket specifically designed for the Alfen Eve Single Pro-Line, complete with 316L stainless steel screws for customized EV charger installation. Optional cable holder/protector available.
A single bracket specifically designed for the Amina 1, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Amina S, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Charge Amps Aura, complete with 316L stainless steel screws for customized EV charger installation.
En enkelt brakett spesielt designet for Charge Amps Dawn, komplett med 316L rustfritt stålskruer for tilpasset EV-lader installasjon.
A single bracket specifically designed for the Charge Amps Halo, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Compleo eBOX professional, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Compleo Solo premium line, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the CTEK Chargestorm Connected 2, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the DEFA Power, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the DEFA Solid, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Easee Charge Lite, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Eldon One/Duo, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Elinta HomeBox Slim/Lite, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Enovates Single WallBox, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Enua Charge, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for EVBOX Liviqo, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Etrel Inch, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the GARO Entity, complete with 316L stainless steel screws for customized EV charger installation.
En enkel brakett spesielt designet for Go-e Charger PRO, komplett med 316L rustfritt stålskruer for tilpasset EV lader installasjon.
En enkelt brakett spesielt designet for Huawei SCharger, komplett med 316L rustfritt stålskruer for tilpasset EV-laderinstallasjon.
A single bracket specifically designed for the Garo GLB, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Garo GTB, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
En enkelt brakett spesielt designet for ghostONE eCharge, komplett med 316L rustfritt stålskruer for tilpasset EV-laderinstallasjon.
A single bracket specifically designed for the KEBA KeContact P30, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the NexBlue Edge, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the QUDO, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Schneider EVlink Gen. 1 FB, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Schneider EVlink Pro, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Vestel evc04, this bracket is also compatible with the Webasto Unite charger. Complete with 316L stainless steel screws for customized EV charger installation.
En enkelt brakett spesielt designet for Wallbox Commander II, komplett med 316L rustfritt stålskruer for tilpasset EV-laderinstallasjon.
A single bracket specifically designed for the Wallbox Copper SB, complete with precision-crafted 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for the Zaptec GO, complete with 316L stainless steel screws for customized EV charger installation.
A single bracket specifically designed for Zaptec Pro, complete with 316L stainless steel screws for customized EV charger installation.
Quattro installation bracket holder facilitates the mounting of multiple brackets for chargers depending on the size of the charger. Quattro offers multiple mounting directions, allowing for customization based on the specific space and environmental requirements.
Designed for Side by Side installations, this bracket holder enables the convenient side-by-side mounting of two charger brackets, optimizing space and functionality.
Specifically designed for side-by-side installations, this bracket holder allows for efficient mounting of two charger brackets, optimizing both space and functionality. It can be easily installed on a pedestal or directly on a wall without compromising cable access, ensuring clean and organized installations. The design preserves full accessibility for cable entry. By mounting two of these bracket holders together, the system can support up to four chargers, creating a versatile quattro bracket holder while maximizing space and installation flexibility.
Lighting bracket used for ONEPOLE PRO Roof 350x600mm dimensions. Typical installation is 2+0.
Lighting bracket used for ONEPOLE PRO Roof Cover Duo 350. Typical installation is 1+0 / 1+1.
Lighting bracket used for ONEPOLE PRO Roof 600x600mm dimensions. Typical installation is 2+2 or Quattro (Charger on all sides of the pedestal)
Customized roof cover designed to fit the ONEPOLE PRO pedestal with dimensions of 350x350mm. Typical installation is 1+0 / 1+1.
Customized roof cover designed to fit the ONEPOLE PRO pedestal with dimensions of 600x600mm.Typical for quattro installation 1+1+1+1 / 2+2
Customized roof cover designed to fit the ONEPOLE PRO pedestal with dimensions of 350x600mm. Typical installation is 2+0.
This top lantern offers an excellent opportunity to enhance the prominence of a pedestal by illuminating its upper section. It can be installed with a roof, combined with a roof and lighting bracket, or positioned independently atop the pedestal. Customization options are available in form of the integration of your logo for a personalized touch.
A blind lid panel fitted in the upper access entry of a ONEPOLE pedestal.
Blindlid (blanking panel) panel with pre drilled 2x 30mm hole for TET 14-20 nippel.
The ONEPOLE PRO Blind Lid Octo serves two key functions. Firstly, it can enclose and shield the spaces between EV chargers when the Quattro bracket is installed. Secondly, it can act as a front enclosure for the pedestal when the pedestal is mounted without a charger.
An access panel installed in the middle access entry of a ONEBLOC foundation.
An access panel installed in the lower access entry of a ONEPOLE pedestal.
Top Lid bracket to close off the ONEPOLE PRO pedestal. 116x116mm dimension.
Adapter designed for use with the Kempower Satellite pedestal. Intended for installation with a dredging foundation 750 C/C 160mm (Q13Y9).
En kabelbeskytter fungerer som et valgfritt tilbehør til EVBOX Liviqo-braketten, og tilbyr ekstra skjerming for kabler som kobles til EV-laderen. I ONEPOLE-porteføljen er to varianter tilgjengelige: en med delt design for å romme kabler, og en annen uten en delt, som gir full dekning for kablene.
A cable protector serves as an optional accessory for the Alfen Eve Single Pro-Line bracket, offering supplementary shielding for cables that connect to the EV charger.
A cable protector serves as an optional accessory for the EVBOX Liviqo bracket, offering supplementary shielding for cables that connect to the EV charger. In the ONEPOLE portfolio, two variants are available: one with a split design for accommodating cables, and another without a split, providing complete coverage for the cables.
Combined cable- and plug holder in one simple design. Combined cable- and plug holder in one simple design. Outer housing is made of powdercoated aluminum and the inner part is made of recycled plastic or ocean plastic. The Cliff Ocean cable holder offers two mounting options: 1) Directly affixed to the pedestal using a Cliff Ocean adapter. 2) Independently installed in any space, often on a wall.
Introducing our 6-Pole Connection Kit, designed for effortless integration of multiple chargers, seamless daisy-chaining of multiple pedestals, or straightforward circuit breaker installations. This comprehensive kit comprises five 6-pole connectors and an earth cable, ensuring a hassle-free and secure electrical connection solution. Mounting the connection kit onto the pedestal is optional and not required. To facilitate the mounting of connection kit directly onto the backplate of the ONEPOLE pedestal, we recommend utilizing M5 8mm bolts. Please note that these bolts are not included in the delivery and should be sourced separately.
The ONEPOLE PRO DIN Connection Kit is a reliable feed-through terminal designed for both copper and aluminum conductors. Specifically tested for compatibility, it integrates seamlessly with the ONEPOLE PRO pedestal equipped with DIN rails. This kit ensures easy installation and delivers high operational reliability, making it an ideal solution for secure and efficient electrical connections. Specifications: • Rated Current: 152 A • Rated Voltage: 1000 V • Operating Temperature: -50 to 130 °C • Material: Thermoplastic • Mounting Method: DIN rail 35 mm • Flame Resistance: UL94 V0 standard • Copper Conductor Cross-Section: 2.5 mm² to 25 mm² • Aluminum Conductor Cross-Section: 4 mm² to 25 mm² Tested in accordance with IEC 60947-7-1, IEC 61238-1, VDE 0603-2
Specially designed Footplate tailored for ONEPOLE PRO pedestals. Delivered with centerdistance on bolts C/C 160 mm for attachment to standard foundations. The footplate is designed for versatile mounting options, allowing it to be easily installed on both ceilings and floors.
The information sign, measuring 245x310mm, is designed for versatile installation. It can be mounted on a pedestal with the information table facing right or left side. The Infosign is typically mounted beneath the EV-charger bracket.
The information sign is designed for flexible installation, allowing it to be mounted on any side of the pedestal to meet customer needs. It is typically used to label and mark specific parking spaces or provide additional information to users. The versatile design makes it suitable for various applications, ensuring clear communication in both indoor and outdoor settings. An additional standard label/sticker kit is available for purchase, or you can opt for customized labels tailored to your specific needs. If you require custom labels, please contact us for assistance. Optional Accessory: ONEPOLE PRO Sticker Set, available in two versions: Set Number 1-20 (QBB9Z) and Set Number 21-42 (QBBB0).
A single bracket specifically designed for the Payment terminals, complete with 316L stainless steel screws for customized payment terminals installation.
The Pillar Flex bracket enables the installation of one or multiple EV chargers on pillars, providing a space-efficient solution for example in garages where space is limited. Compatible with all our charger brackets, the Pillar Flex bracket can be mounted independently or secured with steel bands. For optimal performance, it should be ordered with the Pillar Flex steel band kit.
Pilar flex steel band for mounting Pillar Flex bracket. Instruction for mounting: 1) Pull out the band to the required length plus about 50mm and cut to size 2) Feed the band into the plate, keeping the rack positioned as shown on the picture n. 2 3) Fold the band back on itself 180 degrees using pliers 4) Secure properly using a screwdriver 5) The clip is ready connected and locked For more information, please see the manual.
A custom-designed single bracket is tailored for the Cliff Ocean Q9TMT, serving as a convenient solution for holding both cable and plug in one place. This bracket can be effortlessly installed beneath the wallbox charger. Crafted with precision, the bracket is accompanied by specialized 316L stainless steel screws for securing the Cliff Ocean unit on our ONEPOLE PRO pedestal.
Introducing our enhanced safety bollard, designed to safeguard the Onepole pedestal in bustling environments. This crucial add-on offers protection against potentially destructive forces, mitigating the risk of high damage incidents. Equipped with a convenient mounting bracket, our safety bollard effortlessly attaches to both existing Onepole installations and new ones, ensuring a seamless and hassle-free setup process.
Simple cable holder. Must be installed prior to attaching the charger backplate/charger mounting bracket.
Cable holder for wall mounting, powder coated aluminum, ISO C4 category
To transition from the existing Ø60 dredged foundation to a CC160 footplate pattern, this solution includes bolts for securely fastening the ONEPOLE Base. The "R" signifies Recessed.
The anchor frame has been engineered to seamlessly integrate with the ONEPOLE PRO pedestals, making it the ideal choice for in-ground concrete installations with a precise 160mm center-to-center (C/C) spacing.
Innovativ, holdbar og miljøvennlig grunnlag for ladestasjoner og pullerter. Passer både til CC140 og CC160. Vi presenterer ONEPOLE PRO Base Mount, en innovativ løsning som kombinerer rask installasjon, høy holdbarhet og bærekraft. Vår fundamentering oppfyller strenge krav til korrosjonsbestandighet og levetid, selv under krevende forhold. Hovedfordeler: · Rask installasjon: Kan monteres på 1-2 minutter med et klikk-og-bøy-system som bare krever en justerbar skiftenøkkel. Ingen støping nødvendig; grav det bare ned i bakken. · Høy kvalitet og selvhelende overflate: Base Mount er laget av Aluzink, kjent for sin overlegne korrosjonsbestandighet, ideell for forankring i jord. Dette materialet er velprøvd i lignende applikasjoner over hele Europa. · Fleksibel boltplassering: Kompatibel med nåværende og fremtidige stolper, inkludert lys- og sikkerhetspullerter. · Stabil i alle jordtyper: Justerbar baseplate, som kan foldes ut eller inn, forbedrer stabiliteten i forskjellige jordtyper, enten det er smale kabelgrøfter, sand, leire eller lettere jord. · Vind-testet og sertifisert: Overholder europeiske standarder, noe som gir ekstra forsikring. · Presisjonsnivellering med Bulls Eye: Lar nivellering før, under og etter installasjon for større nøyaktighet og fleksibilitet. · Effektiv logistikk og norsk kvalitet: Transporter opptil 126 enheter per pall for kostnadsbesparelser og effektivitet. Flatpakket og produsert i Norge for lokal kvalitet og bærekraftig produksjon.
Innovative, durable, and eco-friendly foundation solution for charging stations and bollards. This version is typically delivered as a multipack on a pallet, with quantities ranging from 10 to 126 foundations, depending on your project requirements. We present the ONEPOLE PRO Base Mount, an innovative solution that combines quick installation, high durability, and sustainability. Our foundation meets strict requirements for corrosion resistance and longevity, even under demanding conditions. Key Benefits: · Quick Installation: Can be mounted in 1-2 minutes with a click-and-bend system that only requires an adjustable spanner. No casting needed; simply dig into the ground. · High Quality and Self-healing surface: Base Mount is from Aluzink, known for its superior corrosion resistance, ideal for anchoring in soil. This material is well-proven in similar applications across Europe. · Flexible Bolt Spacing: Compatible with current and future poles, including lighting and security bollards. · Stable in All Soil Types: Adjustable base plate, which can be folded out or in, enhances stability in various soil types, whether it's narrow cable trenches, sand, clay, or lighter soils. · Wind-Tested and Certified: Complies with European standards, providing extra assurance. · Precision Leveling with Bullseye: Allows leveling before, during, and after installation for greater accuracy and flexibility. · Efficient Logistics and Norwegian Quality: Transports up to 126 units per pallet for cost savings and efficiency. Flat-packed and produced in Norway for local quality and sustainable production.
Festet med 4 stk M20 bolter montert med største C/C avstand fundamentene er beregnet for. Alle varianter kan benyttes til stolper som krever mindre C/C avstand på boltene. Fundamentene har også en nedfelling i bunnen som muliggjør kabelføring under fundamentet. Stolper kan enkelt justeres mens fundamentet setter seg. Fundamentene settes på linje i grøft slik at åpning for kabelinnføring peker mot tilførselen for kablene. Kabelinnføringen er tosidig. Høyden til kabelinnføringen er fleksibel. Fundamentet er tilpasset innføring av trekkerør for dimensjon 110 mm
Designed for installation on already prepared lots, especially in situations where digging is challenging or undesirable, this solution is ideal for parking lots and temporary charging stations. Its effortless integration with existing infrastructure makes it a seamless choice. The necessary cabling and piping are conveniently added above ground within 110mm pipes. ONEBLOC is tailored to perfectly complement the ONEPOLE system, incorporating the ONEPOLE base 1000 (RAL9005) Shorty, providing an approximate height of 1.5 meters.
ONEPOLE PRO Angled Footplate Bracket 90deg, a versatile, aluminium, powder-coated fixture, enables secure ONEPOLE mounting on vertical surfaces in both upward and downward directions. Includes 4 bolts for ONEPOLE attachment. Suitable for indoor/outdoor use. Attention: Concrete screws are not included.
This universal leveler is specifically designed for ONEPOLE PRO Base Mount but also other foundations with CC160 or CC140 bolt alignment, ensuring precise and quick leveling. It simplifies the alignment process between the foundation and the ONEPOLE PRO pedestal, making installation faster and more accurate.
Ceiling or floor bracket for adjusting the positioning of the footplate, with provisions for accommodating multiple cable entries without compromising structural integrity.
Six-meter galvanized steel pipe.
Aluminium pipe Ø60mm and length of 6000 mm.
Galvanised steel pipe Ø60mm for SR60 adapter.
